Polywedge Screen Panels

Polywedge Screen Panels

(Polyurethane Framed Wedge Wire Screen Media)

Polywedge Screen Panels are a premium composite screening media that combines the high open area and superior drainage performance of stainless steel wedge wire with the wear resistance and noise reduction advantages of polyurethane framing. Designed for demanding mineral processing applications, Polywedge panels are widely used in coal preparation plants, dense medium recovery circuits, dewatering systems, and fine particle classification processes.

Compared with conventional polyurethane screen panels or all-metal wedge wire screens, Polywedge technology offers an optimized balance between screening efficiency, service life, and maintenance costs. The precision profile wire structure delivers excellent drainage performance and minimizes material blinding, while the polyurethane frame provides outstanding impact resistance and simplifies modular installation.

Polywedge Screen Panels are particularly suitable for high-capacity screening operations where accurate cut size, maximum throughput, and reduced downtime are essential.

Typical Applications

Polywedge Screen Panels are extensively used in:

• Coal washing and coal beneficiation plants
• Dense medium recovery (DMR) systems
• Fine coal and mineral dewatering
• Iron ore processing plants
• Gold ore beneficiation circuits
• Slurry screening operations
• Sand and aggregate dewatering systems
• Mineral processing and classification plants
• Tailings dewatering applications
• High moisture material screening

Their precision slot apertures provide superior drainage capabilities while maintaining excellent separation efficiency for fine particles.

Key Advantages

High Open Area & Maximum Drainage Efficiency

The stainless steel wedge wire profile significantly increases the open screening area compared with traditional perforated or woven media. This improves water removal rates and increases screening capacity.

Superior Wear Resistance

Heavy-duty polyurethane framing absorbs impact loads and protects the wedge wire assembly from premature failure, making Polywedge media highly suitable for abrasive mineral applications.

Non-Blinding & Non-Pegging Design

The V-shaped profile wire construction reduces material build-up and minimizes pegging problems during wet screening and dewatering operations.

Reduced Noise Levels

Polyurethane encapsulation dramatically lowers operational noise compared with conventional metallic screening media.

Modular & Easy Installation

Polywedge panels are available in multiple fixing systems including Pin & Sleeve, Fast-Fit, Snap-In, Rail Mounted, and Bolt-Down configurations for easy replacement and compatibility with existing screening equipment.

Structural Design Features

Polywedge Screen Panels are manufactured using:

• Polyurethane Encapsulated Wedge Wire
• Stainless Steel Profile Wire
• PU Framed Wedge Wire Media
• Modular Composite Screening Panels

Available materials include:

• SS304 Stainless Steel
• SS316 Stainless Steel
• Customized corrosion-resistant alloys

The polyurethane frame is molded to provide excellent dimensional stability and superior bonding strength with the wedge wire assembly.

Technical Specifications

Available Fixing Systems

To accommodate different vibrating screen systems, Polywedge panels are available with:

• Pin & Sleeve System
• H-Pin & H-Sleeve System
• Snap-Fit System
• Fast-Fit System
• Rail Mounted System
• Bolt-Down System

Customized dimensions and interfaces can be manufactured according to customers’ drawings or OEM specifications.

Compatible Replacement Options

Our Polywedge Screen Panels are designed as aftermarket replacement solutions for various international modular screening systems and can be manufactured according to customer requirements.

Suitable for replacement of:

• Multotec Polywedge Screen Panels
• Poly-Wedge Screen Media Systems
• Modular Wedge Wire Panels
• Dense Medium Recovery Screen Panels
• Mineral Processing Dewatering Panels

Why Choose Polywedge Screen Panels?

Polywedge media delivers exceptional drainage performance, increased throughput, and significantly longer service life than conventional metallic or polyurethane-only screen media.

For mineral processing operations seeking maximum efficiency and minimum maintenance costs, Polywedge Screen Panels provide an ideal solution for high-performance wet screening applications.

RFQ Information Required

Please provide the following information for quotation:

1. Application material (coal, iron ore, gold ore, etc.)
2. Slot opening size (mm)
3. Panel dimensions (Length × Width × Thickness)
4. Existing screen machine brand or model
5. Fixing system type
6. Stainless steel material grade required
7. Quantity required
8. Operating conditions and throughput
9. Drawings or samples (if available)
