Crusher wear parts

Parameters

Description

Crusher wear parts are essential components in crushing systems used in mining, quarrying, aggregate production, recycling, and construction industries. These consumable parts directly affect crushing efficiency, particle shape, operational stability, and production costs.
HUATAO GROUP supplies a complete range of premium crusher wear parts including:
Jaw Crusher Jaw Plates
Impact Crusher Blow Bars
Cone Crusher Mantle & Concave

Manufactured with high manganese steel, high chrome iron, alloy steel, and composite materials, our wear parts are engineered for high abrasion resistance, impact toughness, and long service life under demanding working conditions.

Product Selection Guide

Wear Part	Crusher Type	Recommended Material	Suitable Material
Jaw Plate	Jaw Crusher	Mn18Cr2	Granite Hard Ore
Mantle & Concave	Cone Crusher	Mn22Cr2	Medium-High Hardness Ore
Blow Bar	Impact Crusher	High Chrome Iron	Limestone Concrete

Jaw Crusher Jaw Plate

Application

Used in jaw crushers for primary crushing of hard rocks and ores through compressive force.

Advantages

Excellent wear resistance
Optimized tooth profile improves crushing efficiency
Reduces vibration and operating noise
Extends replacement cycle
Improves material gripping performance

Common Materials

Mn13
Mn18Cr2
Alloy steel
Composite high chrome inserts

Technical Specifications

Parameter	Range
Thickness	50-250 mm
Length	300-2500 mm
Tooth Height	20-100 mm
Hardness	200-400 HB
Tensile Strength	≥850 MPa

Impact Crusher Blow Bar

Application

Installed on impact crusher rotors for crushing limestone, concrete, asphalt, and construction waste.

Advantages

High impact toughness
Strong fracture resistance
Large reduction ratio
Uniform product size
Easy replacement
Low maintenance cost

Common Materials

High Chrome Iron Cr15-Cr26
High manganese steel
Alloy steel
Ceramic insert composite

Technical Specifications

Parameter	Range
Length	200-1800 mm
Width	100-400 mm
Thickness	50-200 mm
Weight	5-200 kg
Hardness	50-62 HRC

Cone Crusher Mantle & Concave

Application

Used in cone crushers for secondary and tertiary crushing of medium and high hardness materials.

Advantages

Precision casting technology
Stable cavity geometry
Uniform wear distribution
Better particle shape
Reduces flaky particles
High throughput efficiency

Common Materials

Mn18Cr2
Mn22Cr2
Ultra-high manganese steel
Mo/Ni alloy steel

Technical Specifications

Component	Diameter	Weight	Hardness
Mantle	300-2000 mm	50-5000 kg	220-380 HB
Concave	500-2500 mm	100-8000 kg	220-380 HB

FAQ

1.Does Huatao Can produce the Crushing Wear Parts as client drawing?

Yes, we can OEM .

2.What is your package method?

The commonly package is carton box if shipping by courier, or package by wooden box if shipping by sea.

3.To recommend the correct crusher wear parts please provide:

Crusher brand and model OEM part number (if available) Material being crushed Feed size and output size Working condition and abrasiveness Required quantity Drawings or photos (if available)

4.Why Choose Huatao？

Material Excellence Premium alloy materials with advanced heat treatment technology. Precision Engineering Custom-fit for Metso, Sandvik, Terex, Symons, Shanbao and other crusher brands. Longer Service Life Optimized wear profiles improve uptime and reduce replacement frequency. Better Crushing Efficiency Improves throughput and particle shape quality. Lower Operating Cost Reduces downtime and maintenance expenses.
